Welded Mesh Fence Panels for Highway Security, Hot Dipped Galvanized or PVC Coated

Highway Fence Panels Material: High quality low carbon steel wire, high carbon steel wire, galvanized iron wire (Q195 & Q235)

It is made by welded of wire mesh to form panels or sheets with uniform opening and firm structure.

Metal wire mesh fences and beam guardrails, sound barriers are three important fencing products for highway security and crowd control.

54

Color: The wire fence has rich colors: Green RAL6005, Black RAL9005, Blue, Grey, Brown, Yellow etc colors as your request.

Fence Panels Application: Widely used for prevention for road, highway, railway, garden, airport, residential district, seaport, feeding and husbandry,military base

Fence Panel Process: Wire Drawing → Wire Straightening & Wire Cutting → Welding → Folds/Curves Bending → Electric Galvanizing/Hot-dipped Galvanizing → Parkerizing → PVC Coating /Spraying → Packing → Loading

Fence Post Process: RawMaterial → Cutting → Hole Drilling → Electro Galvanizing/Hot-dipped Galvanizing → Sandblasting → PVC Coating/Spraying → Packing → Loading

7855

Wire Mesh Fence Specification with Square Post

Size 40*60mm, 50*50mm, 60*60mm, 80*80mm
Thickness 1.2mm, 1.5mm, 2.0mm
Height 1.3m, 1.5m, 1.6m, 1.8m, 2.0m, 2.5m, 3.0m
Surface Elec. Gal., Hot-dip Gal., Powder spray, Deep Powder coated
Clip Plastic, Metal

Wire Mesh Fence Specification with Round Post

Size 38mm, 40mm, 42mm, 60mm
Thickness 1.2mm, 1.5mm, 2.0mm
Height 1.5m, 1.6m, 1.8m, 2.0m, 2.5m
Surface Elec.Gal., Hot-dip Gal., Powder spray, Deep Powder coated

Wire Mesh Fence Specification with Peach Post

Size 50*70mm, 70*100mm
Thickness 1.2mm
Height 1.5m, 1.8m, 2.0m, 2.5m
Surface Pre hot dipped galvanized + Powder Spray

637

Package
Fence panel: Plastic film for every piece in bulk or Wooden/Metal Pallet
Fence post: Plastic film + Wooden/Metal Pallet
Accessories: In woven bags or Cardboard boxes

Feature: It can quickly and easily be installed, without the need to disturb the surface area by digging holes or laying foundations

Specifications of Fence Panels with Fencing Gates:

The type of the vertical- hinged door Single door
Double door
Height of the gate (mm) 1.0m, 1.2m, 1.5m, 1.8m, 2.0m
Width of the gate (mm) Single leaf: 1m, 1.2m, 1.5m
Double leaf: 2m, 3m, 4m, 5m, 6m, 8m
Gate frame surface Square tubes: 35X35mm, 40X40mm, 50mmX50mm, 60mmX60mm
Surface treatment Galvanized Steel pipe+ high adhesion electrostatic spraying processing
Color RAL 6009 colors

Wire diameter 4mm, 4.8mm, 5mm, 6mm
mesh size 50*100mm, 50*150mm, 50*200mm
height 1.5m, 2.2m, 2.4m,
Single gate size 1.5*1m, 1.7*1m
post 40*60*1.5mm, 60*60*2mm
Surface treatment Electric galvanzied then Powder coated, hot-dipped
b_5567781202106051623497683
